# Prometheus & Grafana: From Zero to Production Monitoring

Setting up monitoring shouldn't require a PhD. Here's how I set up Prometheus and Grafana for our production infrastructure, explained like you're implementing it tomorrow.

The Problem

Our services kept having mystery outages. By the time we noticed, customers were already complaining. We needed visibility, fast.

Why Prometheus + Grafana?

• After trying CloudWatch, Datadog, and New Relic:
• **Prometheus**: Open source, pull-based, perfect for Kubernetes
• **Grafana**: Beautiful dashboards, free, integrates with everything
• **Cost**: ~$0 (self-hosted) vs $500+/month for commercial solutions

Let's build this.

Setup: The Docker Compose Way

For development or small deployments, Docker Compose is perfect:

version: '3.8'

services: prometheus: image: prom/prometheus:latest container_name: prometheus volumes: - ./prometheus.yml:/etc/prometheus/prometheus.yml - prometheus_data:/prometheus command: - '--config.file=/etc/prometheus/prometheus.yml' - '--storage.tsdb.path=/prometheus' - '--storage.tsdb.retention.time=30d' ports: - "9090:9090" restart: unless-stopped

grafana: image: grafana/grafana:latest container_name: grafana volumes: - grafana_data:/var/lib/grafana - ./grafana/provisioning:/etc/grafana/provisioning environment: - GF_SECURITY_ADMIN_PASSWORD=changeme - GF_USERS_ALLOW_SIGN_UP=false ports: - "3000:3000" restart: unless-stopped depends_on: - prometheus

node_exporter: image: prom/node-exporter:latest container_name: node_exporter command: - '--path.procfs=/host/proc' - '--path.sysfs=/host/sys' - '--collector.filesystem.mount-points-exclude=^/(sys|proc|dev|host|etc)($$|/)' volumes: - /proc:/host/proc:ro - /sys:/host/sys:ro - /:/rootfs:ro ports: - "9100:9100" restart: unless-stopped

  prometheus_data:
  grafana_data:

• *Run it:**

docker-compose up -d

Done. Prometheus is on :9090, Grafana on :3000.

Prometheus Configuration

Create prometheus.yml:

global:
  scrape_interval: 15s
  evaluation_interval: 15s
  external_labels:
    cluster: 'production'
    region: 'us-east-1'

Alertmanager configuration (we'll get to this) alerting: alertmanagers: - static_configs: - targets: ['alertmanager:9093']

Load rules rule_files: - 'alerts/*.yml'

Scrape configurations scrape_configs: # Prometheus itself - job_name: 'prometheus' static_configs: - targets: ['localhost:9090']

# Node metrics (CPU, memory, disk) - job_name: 'node' static_configs: - targets: ['node_exporter:9100'] labels: instance: 'production-server-1'

  - job_name: 'webapp'
    static_configs:
      - targets: ['webapp:8080']
    metrics_path: '/metrics'

Instrumenting Your Application

Node.js/Express Example

const express = require('express');
const promClient = require('prom-client');

const app = express(); const register = new promClient.Registry();

// Collect default metrics (CPU, memory, event loop) promClient.collectDefaultMetrics({ register });

// Custom metrics const httpRequestDuration = new promClient.Histogram({ name: 'http_request_duration_seconds', help: 'Duration of HTTP requests in seconds', labelNames: ['method', 'route', 'status_code'], buckets: [0.1, 0.5, 1, 2, 5] });

const httpRequestTotal = new promClient.Counter({ name: 'http_requests_total', help: 'Total number of HTTP requests', labelNames: ['method', 'route', 'status_code'] });

register.registerMetric(httpRequestDuration); register.registerMetric(httpRequestTotal);

// Middleware to track requests app.use((req, res, next) => { const start = Date.now(); res.on('finish', () => { const duration = (Date.now() - start) / 1000; const labels = { method: req.method, route: req.route?.path || req.path, status_code: res.statusCode }; httpRequestDuration.observe(labels, duration); httpRequestTotal.inc(labels); }); next(); });

// Metrics endpoint app.get('/metrics', async (req, res) => { res.set('Content-Type', register.contentType); res.end(await register.metrics()); });

  console.log('Server running on :8080');
  console.log('Metrics available at /metrics');
});

Python/Flask Example

from flask import Flask, request
from prometheus_client import Counter, Histogram, generate_latest
import time

app = Flask(__name__)

Metrics request_count = Counter( 'http_requests_total', 'Total HTTP requests', ['method', 'endpoint', 'status'] )

request_duration = Histogram( 'http_request_duration_seconds', 'HTTP request duration', ['method', 'endpoint'] )

@app.before_request def before_request(): request.start_time = time.time()

@app.after_request def after_request(response): duration = time.time() - request.start_time request_count.labels( method=request.method, endpoint=request.endpoint, status=response.status_code ).inc() request_duration.labels( method=request.method, endpoint=request.endpoint ).observe(duration) return response

@app.route('/metrics') def metrics(): return generate_latest()

    app.run(host='0.0.0.0', port=8080)

Essential Queries

CPU Usage

# CPU usage percentage
100 - (avg by (instance) (rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100)

Per core rate(node_cpu_seconds_total{mode!="idle"}[5m]) ```

Memory Usage

# Memory usage percentage
(1 - (node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes)) * 100

Available memory node_memory_MemAvailable_bytes / 1024 / 1024 / 1024 ```

Disk Usage

# Disk usage percentage
(1 - (node_filesystem_avail_bytes / node_filesystem_size_bytes)) * 100

Filter to only important mounts (1 - (node_filesystem_avail_bytes{mountpoint="/"} / node_filesystem_size_bytes{mountpoint="/"})) * 100 ```

HTTP Request Rate

# Requests per second
rate(http_requests_total[5m])

By status code sum by (status_code) (rate(http_requests_total[5m])) ```

HTTP Latency

# 95th percentile latency
histogram_quantile(0.95, rate(http_request_duration_seconds_bucket[5m]))

Average latency rate(http_request_duration_seconds_sum[5m]) / rate(http_request_duration_seconds_count[5m]) ```

Grafana Dashboards

Import Community Dashboards

1. Go to Grafana → Dashboards → Import
2. Use these IDs:
3. - **1860**: Node Exporter Full
4. - **3662**: Prometheus 2.0 Overview
5. - **7362**: MySQL Overview

Or create custom dashboards with the queries above.

Auto-Provisioning Datasource

Create grafana/provisioning/datasources/prometheus.yml:

apiVersion: 1

  - name: Prometheus
    type: prometheus
    access: proxy
    url: http://prometheus:9090
    isDefault: true
    editable: false

Alerting That Actually Works

Create alerts/rules.yml:

groups:
  - name: system_alerts
    interval: 30s
    rules:
      # High CPU
      - alert: HighCPUUsage
        expr: 100 - (avg(rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100) > 80
        for: 5m
        labels:
          severity: warning
        annotations:
          summary: "High CPU usage on {{ $labels.instance }}"
          description: "CPU usage is {{ $value }}%"

# High Memory - alert: HighMemoryUsage expr: (1 - (node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes)) * 100 > 85 for: 5m labels: severity: warning annotations: summary: "High memory usage on {{ $labels.instance }}" description: "Memory usage is {{ $value }}%"

# Disk Space - alert: DiskSpaceLow expr: (1 - (node_filesystem_avail_bytes{mountpoint="/"} / node_filesystem_size_bytes{mountpoint="/"})) * 100 > 85 for: 5m labels: severity: critical annotations: summary: "Disk space low on {{ $labels.instance }}" description: "Disk usage is {{ $value }}%"

# Service Down - alert: ServiceDown expr: up == 0 for: 1m labels: severity: critical annotations: summary: "Service {{ $labels.job }} is down" description: "{{ $labels.instance }} has been down for 1 minute"

      - alert: HighErrorRate
        expr: (sum(rate(http_requests_total{status_code=~"5.."}[5m])) / sum(rate(http_requests_total[5m]))) * 100 > 5
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "High error rate detected"
          description: "Error rate is {{ $value }}%"

Production Considerations

Data Retention

Prometheus stores data locally. For long-term storage:

# prometheus.yml
storage:
  tsdb:
    retention.time: 30d
    retention.size: 50GB

• For longer retention, use:
• **Thanos**: Distributed Prometheus
• **Cortex**: Multi-tenant Prometheus as a service
• **VictoriaMetrics**: Drop-in replacement, more efficient

High Availability

Run multiple Prometheus instances with identical configs. Use a load balancer or Thanos for deduplication.

Security

# Add basic auth
global:
  external_labels:
    cluster: 'production'

In Grafana datasource basicAuth: true basicAuthUser: prometheus basicAuthPassword: supersecret ```

Better: Put behind VPN or use mutual TLS.

Common Gotchas

1. **Scrape interval too low**: Don't go below 10s unless you need it
2. **Too many labels**: Increases cardinality, slows queries
3. **Wrong metric types**: Use Counter for cumulative, Gauge for point-in-time
4. **No alerts**: Monitoring without alerting is useless
5. **Alert fatigue**: Too many alerts = ignored alerts

What to Monitor

The Golden Signals (Google SRE)

1. **Latency**: How long requests take
2. **Traffic**: Request rate
3. **Errors**: Error rate
4. **Saturation**: Resource usage (CPU, memory, disk)

If you only monitor four things, monitor these.

Next Steps

1. Add more exporters (MySQL, Redis, etc.)
2. Set up Alertmanager with Slack/PagerDuty
3. Create runbooks for each alert
4. Configure backup for Prometheus data
5. Explore Grafana plugins

Conclusion

This setup has saved our bacon multiple times. We now know about issues before customers do.

The best monitoring is monitoring you actually use. Start simple, iterate, and add complexity only when needed.

• *Remember**: A dashboard you never look at is just pretty graphs wasting electricity.

Got questions? Run into issues? Drop a comment below!
